Model: Epson DS-1630
Type: Sheetfed & Flatbed Scanner
Resolution: 1200dpi (Flatbed), 600dpi (ADF)
Sheet Capacity (ADF): Yes
Interface (Build-in): USB
Duty Cycle (Daily): 1500 Pages
| Scan Technology | Contact Image Sensor (CIS) |
| Scanning Speed (B & W) | 25ppm/ 10ipm |
| Scanning Speed (Color) | 25ppm/ 10ipm |
| Scanning Speed (Gray) | 25ppm/ 10ipm |
| Resolution | 1200dpi (Flatbed), 600dpi (ADF) |
| Scan Size | Legal, A4, Letter, A5, A6 |
| Scan Size Max. | Legal |
| Color Bit Depth | 30-bits (internal / external) |
| Grayscale Bit Depth | 8-bit per pixel internal / external |
| Color Scanning | Yes |
| Scanning Capability | Black & White, Color |
| Scan Drivers Included | TWAIN and ISIS |
| Duplex Scan | Automatic |
| ADF | Yes |
| Sheet Capacity (ADF) | 50 Sheets |
| Paper size (ADF) | 8.5 Inch x 11.7 Inch duplex/simplex, 8.5 Inch x 14 Inch simplex (Max), 3.5 Inch x 6.7 Inch duplex, 3.5 Inch x 5 Inch simplex (Min) |
| Max. Scan Paper Size ADF | Legal |
| Min. Scan Paper Size ADF | 88.9 x 127mm |
| Paper Weight | 50 to 120 g/m2 |
| Media Type | N/A |
| Automatic Document Feeder Speed | N/A |
| Scanning Options (ADF) | Yes |
| Light Source Type | 3-color LED technology |
| Image Sensor | Contact Image Sensor (CIS) |
| Control Panel | 3 buttons- Power, Scan, Stop |
| Processor Speed | N/A |
| MICR/ OCR | ABBYY FineReader OCR |
| Interface (Built-in) | USB |
| Interface (Optional) | RJ-45, 10BaseT/100BaseTX |
| USB Type | USB 3.0 |
| Wireless Network Interface | N/A |
| Network Interface (RJ45) | N/A |
| Button | Yes |
| ISIS Compatibility | Yes |
| Twain Compatibility | Yes |
| Twain Version | Windows 7, 8, 8.1, 10, Mac OS X 10.6.8 - 10.11.x |
| Multi Feed Detection | N/A |
| Supported Operating System | N/A |
| Power Supply | AC 100 - 120V |
| Operating Temperature Range | N/A |
| Rated Voltage | N/A |
| Approx. Power Consumption | Opertaing mode: 11 W, Ready mode: 5.8 W, Sleep mode: 0.8 W, Off: 0.15 W |
| Product Form Factor | N/A |
| Duty Cycle (Daily) | 1500 Pages |
| Color | Black & White |
| Dimensions | 317.5 x 121.92 x 297.18mm |
| Weight | 4.08Kg |
| Warranty | 1-Year Warranty |
| Specialty | Versatile scanning from a leader in image capturing technology, Scan stacks of documents up to 25 ppm, Seamless compatibility with document management systems, Scan to online storage accounts, Organize easily with the included software suite, Streamline your workflow, Scan originals in a variety of sizes, Generate searchable and editable files, Intelligent color and image adjustments, Send scans to any computer on network |
Epson DS-1630 – Reliable Flatbed and Sheetfed Scanner for Fast Document Management
The Epson DS-1630 is a hybrid scanner that combines the flexibility of a flatbed with the speed of a 50-sheet automatic document feeder (ADF), offering a complete solution for both single and batch scanning. Ideal for small to mid-sized businesses, this scanner provides fast, efficient, and high-quality results across a wide range of media types and document sizes.
With its fast scan speeds, built-in OCR, USB 3.0 connectivity, and support for both TWAIN and ISIS drivers, the Epson DS-1630 streamlines document digitization for modern work environments.
Key Features
Dual Scanning Flexibility
Enjoy both flatbed and sheetfed scanning in a single compact device—perfect for everything from delicate IDs to thick stacks of documents.
Fast Scanning Performance
Delivers up to 25 pages per minute (simplex) and 10 images per minute (duplex), making it suitable for medium-duty office use.
High-Quality Output
Offers up to 1200 dpi resolution on the flatbed and 600 dpi via ADF to ensure clear, sharp document and photo scans.
Robust Media Handling
Scans media as small as 3.5 × 5 inches and as large as 8.5 × 14 inches. Supports weights between 50–120 g/m², accommodating a range of paper types.
50-Sheet ADF Capacity
Load up to 50 pages into the automatic document feeder for continuous scanning without manual input.
Comprehensive Software Support
Includes ABBYY FineReader OCR for converting scans into editable and searchable files. Compatible with document management systems via TWAIN and ISIS drivers.
Smart Image Enhancement
Built-in features help improve scan quality with automatic color correction, background removal, and text enhancement.
Compact Design and Easy Controls
A space-saving footprint and simple control buttons (Power, Scan, Stop) make this scanner easy to use in any workspace.
Full Specifications
Scanner Type: Sheetfed & Flatbed
Sensor Type: Contact Image Sensor (CIS)
Light Source: 3-color LED
Scan Speed: Up to 25 ppm (simplex), 10 ipm (duplex)
Optical Resolution: 1200 dpi (flatbed), 600 dpi (ADF)
Color Depth: 30-bit internal / external
Grayscale Depth: 8-bit internal / external
ADF Capacity: 50 sheets
Media Sizes Supported:
Max: 8.5 × 14 in
Min: 3.5 × 5 in
Media Weight Supported: 50 – 120 g/m²
Scan Modes: Black & White, Color
Control Panel: 3 buttons (Power, Scan, Stop)
Connectivity:
USB 3.0
Ethernet (RJ-45, 10BaseT/100BaseTX)
Software: ABBYY FineReader OCR
Drivers Supported: TWAIN, ISIS
Operating Systems:
Windows 7, 8, 8.1, 10
macOS X 10.6.8 to 10.11.x
Power Consumption:
Operating: 11 W
Ready: 5.8 W
Sleep: 0.8 W
Off: 0.15 W
Daily Duty Cycle: Up to 1500 pages
Color: Black & White
Dimensions: 317.5 × 121.92 × 297.18 mm
Weight: 4.08 kg
Warranty: 1 Year Official Warranty
Epson DS-1630 Price in Bangladesh
The Epson DS-1630 is built to handle everything from everyday paperwork to legal documents with speed and accuracy. It's the ideal solution for office environments seeking both flatbed and ADF functionality in one efficient device.
Latest Price: {{latest_price}}
Why Buy from Us – Eastern IT
Eastern IT is the best computer shop in Bangladesh and a trusted computer shop in Dhaka, offering professional-grade scanning devices with reliable support. With us, you receive:
Upgrade your office efficiency today with the Epson DS-1630, available at Eastern IT.
